Philips VR550 - Page 63

ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
VR550/02 VR550/07 VR550/16
R101 CARBON RES. 1/4W J 820 OHM 1 1 1
R103 CARBON RES. 1/4W J 820 OHM 1 1 1
R104 CARBON RES. 1/6W J 4.7K OHM 1 1 1
R106 CARBON RES. 1/6W J 4.7K OHM 1 1 1
R108 CARBON RES. 1/4W J 68 OHM 1 1 1
R109 CHIP RES.(1608) 1/10W J 75 OHM 1 1 1
R110 CARBON RES. 1/4W J 820 OHM 1 1 1
R112 CARBON RES. 1/4W J 820 OHM 1 1 1
R113 CARBON RES. 1/6W J 4.7K OHM 1 1 1
R115 CARBON RES. 1/6W J 4.7K OHM 1 1 1
R116 CARBON RES. 1/6W J 15K OHM 1 1 1
R117 CHIP RES.(1608) 1/10W J 10K OHM 1 1 1
R118 CARBON RES. 1/4W J 68 OHM 1 1 1
R119 CHIP RES.(1608) 1/10W J 75 OHM 1 1 1
R120 CARBON RES. 1/6W J 680 OHM 1 1 1
R123 CHIP RES.(1608) 1/10W J 220 OHM 1 1 1
R125 CARBON RES. 1/6W J 680 OHM 1 1 1
R126 CHIP RES.(1608) 1/10W J 220 OHM 1 1 1
R127 CHIP RES.(1608) 1/10W 0 OHM 1 1 1
R128 CHIP RES.(1608) 1/10W 0 OHM 1 1 1
SENSOR CB
A
Q504 9965 000 08630 PHOTO TRANSISTOR PT204-6B-12 1 1 1
Q505 9965 000 08630 PHOTO TRANSISTOR PT204-6B-12 1 1 1
AFV CB
A
CAPACITOR
S
C1 CHIP CERAMIC CAP.(1608) F Z 0.1UF/50V 1 1 1
C4 CHIP CERAMIC CAP. CH J 56PF/50V 1 1 1
C5 CHIP CERAMIC CAP.(1608) CH J 22PF/50V 1 1 1
C6 CHIP CERAMIC CAP. CH J 56PF/50V 1 1 1
C7 CHIP CERAMIC CAP. CH C 3PF/50V 1 1 1
C8 CHIP CERAMIC CAP. CH C 3PF/50V 1 1 1
C11 CHIP CERAMIC CAP.(1608) B K 0.01UF/50V 1 1 1
C12 ELECTROLYTIC CAP. 10UF/16V M H7 1 1 1
C13 CHIP CERAMIC CAP.(1608) B K 0.01UF/50V 1 1 1
C14 CHIP CERAMIC CAP.(1608) B K 0.01UF/50V 1 1 1
C15 ELECTROLYTIC CAP. 10UF/16V M H7 1 1 1
C16 ELECTROLYTIC CAP. 10UF/16V M H7 1 1 1
C17 CHIP CERAMIC CAP.(1608) F Z 0.1UF/50V 1 1 1
C19 CHIP CERAMIC CAP.(1608) F Z 0.1UF/50V 1 1 1
C20 ELECTROLYTIC CAP. 3.3UF/50V M H7 1 1 1
C21 CHIP CERAMIC CAP.(1608) F Z 0.1UF/50V 1 1 1
C22 ELECTROLYTIC CAP. 10UF/16V M H7 1 1 1
C24 ELECTROLYTIC CAP. 0.22UF/50V M H7 1 1 1
CONNECTORS
CN1 4822 265 1126
7
ANGLE PIN HEADER, 9P 6029B-1-09Z003-
T
111
DIODES
D2 4822 130 30621 SWITCHING DIODE 1N4148M 1 1 1
IC’
s
IC1 9965 000 1227
4
IC:AUDIO PROCESSOR MSP3407G-QG-B8 1
IC1 9965 000 12199 IC:AUDIO PROCESSOR MSP3417G-QG-B8 1 1
COILS
L1 4822 157 10889 INDUCTOR 10UH-K-26
T
111
L2 4822 157 10332 PCB JUMPER D0.6-P5.0 1 1 1
L3 4822 157 11318 INDUCTOR 18UH-K-26
T
111
L4 4822 157 10889 INDUCTOR 10UH-K-26
T
111
RESISTORS
R1 9965 000 13036 CHIP RES.(1608) 1/10W J 1K OHM 1 1 1
R4 9965 000 1303
7
CHIP RES.(1608) 1/10W J 120K OHM 1 1 1
R5 9965 000 09942 CHIP RES.(1608) 1/10W 0 OHM 1 1 1
X1 9965 000 12200 X’TAL 18.432MH
Z
111
1-16-10
