• 6 feet of tubing is provided for inlet
and drain connections.
• Feedwater inlet connection is made
through a 3/8” OD push to connect
fitting.
• Feedwater source should be located
within 3 feet of the Phoenix.
• The inlet is the bottom most fitting
on the right side of the Phoenix.
• Ensure tubing is pushed all the way
into fitting.
• An isolation shut off valve is
recommended for servicing purposes.
• Install supplied barbed drain fitting in
labeled drain opening on left side of
Phoenix.
• Insert 3/8” OD tubing (supplied) into
drain fitting and route the other end
to a suitable drain. If a leak occurs, it
will be contained by directing water
to the drain.
