Section 2. Fitting an APM2 in an APM100 Enclosure
2.1 Overview
APM100 pressure monitors from Phoenix Controls can be replaced in the field using the newer APM2 units.
However, it is important to order the Retrofit Kit version of the APM2 product for compatibility with the
existing enclosure. The APM2 Retrofit Kit includes additional parts and modifications to the standard APM2
product that permits easy installation in the field.
These instructions outline how to replace an APM100 series pressure monitor with APM200 series units.
APM100 models installed in the field are housed in a 5-gang single-deep electrical box. The APM2 models
require a 3-gang double-deep electrical box for new installations, so it will not fit directly into the APM1
enclosure without this adapter kit.
2.1.1 What Is Included In Your Kit
• APM2 model with the pressure range you ordered with 90 degree pressure taps on the rear of the unit for
proper seating in the APM100 enclosure
• Stainless steel adapter plate to cover the larger APM100 wall opening
• Four (4) phillips head screws to secure APM2 to the adapter plate
• Four (4) Allen head screws to secure adapter plate to the existing APM100 enclosure
• APM2 white faceplate
• APM2 installation instructions
• APM2 connector kit
• APM2 calibration certificate
2.1.1.1 Not Included - Tools You Will Need
• Small blade terminal screwdriver
• Phillips head screwdriver
• 1/8" Allen wrench
