Phoenix Advanced pressure monitor II - Section 4. Ancillary Product Specifications; Model 264 Pressure Transducer

Ancillary Product Specifications
Model 264 Pressure Transducer
25
MKT-0262 MPC-1748 Rev 02/13
APM2 Rough-In Installation Guide
Section 4. Ancillary Product Specifications
NOTE: The following specifications are subject to changes without notice.
4.1 Model 264 Pressure Transducer
Table 1. Model 264 Pressure Transducer (Remote Transducer 0-5 V Output)
Model 264 Pressure Transducer
Performance Data
Standard Optional
Accuracy
1
RSS (at constant temperature)
± 1.0 % FS ± 0.4 % FS ± 0.25 % FS
Non-linearity (BFSL) ± 0.96 % FS ± 0.38 % FS ± 0.22 % FS
Hysteresis 0.10% FS 0.10% FS 0.10% FS
Non-repeatability 0.05% FS 0.05% FS 0.05% FS
Thermal Effects
2
Compensated Range °F (°C)
0 - 150 (-18 - 65)
Zero/Span Shift % FS/
°F (°C)
0.033 (0.06)
Maximum Line Pressure 10 psi
Overpressure Up to 10 psi (range dependent)
Long-term Stability 0.5% FS / year
Position Effect Range Zero Offset (% FS/G)
Unit is factory calibrated at 0g effect in the
vertical position
To 0.5" WC 0.60
To 1.0" WC 0.50
Environmental Data
Temperature
Operating
3
°F (°C)
0 - +175 (-18 - +79)
Storage
°F (°C)
-65 - +250 (-54 - +121)
Physical Description
Case Fire-retardant glass filled polyster (UL94 V-0 Approved)
Dimensions 2.75" (69.85 mm) W x 5.062" (128.57 mm)H x 2.40" (61.07 mm) D
Mounting
Four screw holes on removable zinc-plated steel base (designed for 2.75"
snap track)
Electrical Connection Screw type terminal strip
