Model 267 Pressure Transducer
4.2 Model 267 Pressure Transducer
Table 2. Model 267 Pressure Transducer
Performance Data
Standard Optional
Accuracy
1
RSS (at constant temperature)
± 1.0 % FS ± 0.4 % FS ± 0.25 % FS
Non-linearity (BFSL) ± 0.98 % FS ± 0.38 % FS ± 0.22 % FS
Hysteresis 0.10% FS 0.10% FS 0.10% FS
Non-repeatability 0.05% FS 0.05% FS 0.05% FS
Thermal Effects
2
Compensated Range °F (°C)
40 - 150 (5 - 65)
Zero/Span Shift % FS/
°F (°C)
± 0.033 (± 0.06)
Maximum Line Pressure 10 psi
Overpressure Up to 10 psi (range dependent)
Warm-up Shift ± 0.1% FS Total
Position Effect Range Zero Offset (% FS/G)
Unit is factory calibrated at 0g effect in the
vertical position
To 0.5" WC 0.60
To 1.0" WC 0.50
Environmental Data
Temperature
Operating
3
°F (°C)
0 - +150 (-18 - +65)
Storage
°F (°C)
+65 - +180 (-54 - +82)
Physical Description
Case IP65/NEMA plastic-filled polycarbonate (UL94 V-0 Approved)
Dimensions 6.20" (158 mm) W x 2.68" (68 mm) H x 3.65" (93 mm) D
Electrical Connection Screw type terminal strip
Electrical Termination
PG-9/PG13.5 Strain relief, 1/2" conduit opening, or 9-pin D-sub connector
NOTE: 9-pin D-sub connector is not suitable for NEMA4/IP-65 environments
Pressure Fittings
3/16" O.D. barbed brass for 1/4" push-on tubing (Standard)
Static Pressure Probe (Optional)
1/4" NPTF brass (Optional)
Weight (approximate) 9 ounces (255 g)
Pressure Media
Typically air or similar non-conducting gases
