Ancillary Product Specifications
Phoenix Recommended Cables
8C No Signal 22 Belden 9421 Manhattan
M13308
1: White
2: Orange
3: Black
4: Red
5: Green
6: Yellow
7: Blue
8: Brown
No
substitutes
8C Yes Signal 22 Comtran 4956 1: White
2: Orange
3: Black
4: Red
5: Green
6: Yellow
7: Blue
8: Brown
No
substitutes
3C
MS/TP
No Shielded 22 Belden 3106A
(120 ohm)
See
specifications
below for
alternate cable
solutions
1: White with Orange
stripe
2: Orange with White
stripe
3: Blue with White
stripe
Shielded
with drain
3C MS/
TP
Ye s Shielded 22 Connect-Air
W223C-
2060YPC
See
specifications
below for
alternate cable
solutions
1: Black
2: White
3: Red
Foil shield
with drain
wire
4C
MS/TP
Yes Armored
Shielded
22 Belden 1269A
(100 ohm)
See
specifications
below for
alternate cable
solutions
1: Red
2: Blue
3: Black
4: Yellow
Foil and
braided
shield with
drain
4C
MS/TP
Yes Armored
Shielded
22 Belden 123107A
(100 ohm)
See
specifications
below for
alternate cable
solutions
1: White with Blue
stripe
2: Blue with White
stripe
3: White with Orange
stripe
4: Orange with White
stripe
Foil and
braided
shield with
drain
4C
MS/TP
Yes Armored
Shielded
24 Belden 82842
(100 ohm)
See
specifications
below for
a
lternate cable
solutions
1: White with Blue
stripe
2: Blue with White
stripe
3: White with Orange
stripe
4: Orange with White
stripe
Foil and
braided
shield with
drain
Low smoke
Cable
Ty p e
Plenum
Rated
Function
Wire
Gauge
Primary
Vendor/Part #
Alternate
Vendor/Part #
Color Code Notes
