Quick Start
7 Start the PI host software you wish to use and set it up for the stage(s)
connected to your system. The sample screen shots that follow are from
PIMikroMove™, though MMCRun can be used instead; more details on
the host software operation are given in the respective software manual.
NOTE
A USB connection will appear as an extra COM port when the controller is
connected, powered up, and the USB drivers are installed.
The baud rate used by the host must be the same as that set on the DIP
switches, even if the USB interface is used!
Fig. 4: PIMikroMove™ Start up Controller screen, Step 1 with “extra” COM port for
USB connection being selected
www.pi.ws C-863 MS173E Release 1.2.7 Page 16
