28
Note: All junction layout examples given in this document
are meant for rough guidance only. Please refer to
Highways Agency specifications for actual signal, sign
and cone placements for any particular junction types.
Example 2: Standalone pedestrian crossing
2 vehicle phases, 2 approaches, 1 head per approach with single pedestrian crossing
This example shows a basic pedestrian crossing and uses the PEDESTRIAN ONLY mode to use the most
appropriate settings.
Note: When the PEDESTRIAN ONLY mode is invoked, all active phases operate as one.
Master
phase
modes
