2.2 Front view
2 Overview
2.2Front view2200Front view2-Klemmenbelegung
Front view with and without cover
Legende__ Klemmenbelegung_m ini_multi_Basis_BA
Key:
 X1:
– Inputs I8 ... I15
 X2:
– Configurable test pulse/auxiliary outputs T0M20 ... T3M23
– Semiconductor outputs O0 ... O3
 X3:
– Configurable inputs/outputs IM0 – IM3
– Inputs I4 ... I7
 X4:
– Configurable inputs/outputs IM16 – IM19
– Supply connections
 LEDs:
–POWER
–RUN
– DIAG
–FAULT
–I FAULT
–O FAULT
X3
X1
X4
X2
PNOZ mm0p
IM0
IM1 IM2 I6
I5
I4IM3 I7
I8
I9 I10 I14
I13
I12I11 I15
X3
X1
X4
X2
PNOZ mm0p
T0
T1 T2 O2
O1
O0T3 O3
IM16
IM17 IM18 0 V
A2
A1IM19 24 V
M20
M21
M22 M23
IM0
IM1 IM2 I6
I5
I4IM3 I7
I8
I9 I10 I14
I13
I12I11 I15
T0
T1 T2 O2
O1
O0T3 O3
IM16
IM17 IM18 0 V
A2
A1IM19 24 V
M20
M21
M22 M23
