2.1 Unit structure
2 Overview
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de
2-2
Display for:
– Error messages
– State of supply voltage
– State of inputs/outputs
– Status information
– Unit information
Monitors shorts across the inputs through test pulse outputs
Monitoring of shorts between the safety outputs
Plug-in connection terminals:
either spring-loaded terminal or screw terminal available as an acces-
sory (see order reference)
Rotary knob for menu control
2.1.3 Chip card
Chip card2-Bestimmung/Gertebeschreibung_multi_Chipkarte
To be able to use the product you will need a chip card.
Chip cards are available with memories of 8 kByte and 32 kByte. For
large-scale projects we recommend the 32 kByte chip card (see Tech-
nical Catalogue). Accessories chapter).
