2-1
2.1 Unit structure
2 Overview
22000OverviewOverview2-2.1Unit structure2100Unit structure2-
2.1.1 Range
Range2-Eigenschaften
 Base unit PNOZ mm0p
2.1.2 Unit features
Unit features2-Gerätemerkmale_Verwendung
Using the product PNOZ mm0p:
Verwendung/Bildunterschrift_multi_Basis
Base unit from the configurable control system PNOZmulti
Geraetemerkmale_Zusatz BA Einleitung
The product has the following features:
Gertemerkmale_multi_Mini_Basis
 Can be configured in the PNOZmulti Configurator
 Semiconductor outputs:
4 safety outputs
Depending on the application, up to PL e of EN ISO 13849-1 and up
to SIL CL 3 of EN IEC 62061
 12 inputs for connecting:
– Emergency stop pushbuttons
– Two-Hand Button
– Safety gate limit switches
– Reset Element
– Light beam devices
– Scanners
– Enable Switch
– PSEN
– Operating Mode Selector Switch
 8 configurable inputs/outputs
Can be configured as:
– Inputs (see above for connection options)
or
– Auxiliary outputs
 4 configurable outputs
Can be configured as:
– Auxiliary outputs
or
– test pulse outputs
 LED for:
– Error messages
– Diagnostics
– Supply voltage
– Output circuits
– Input circuits
