8-1
8.1 Technical details
8 Technical Details
88000Technical DetailsTechnical Details8-8.1Technical details8100Technical details8-][Technische Daten_multi_Basis_Mini
Technical details
Electrical data
Supply voltage U
B
DC 24 V
Voltage tolerance -15 %/+20 %
Power consumption at U
B
DC
without load 8.0 W
with load 35.0 W
Residual ripple DC 5 %
Status display Display, LED
Times
Switch-on delay 5.00 s
Simultaneity channel 1/2/3 3 s
Two-hand circuit 0.5 s
Supply interruption before de-energisation 20 ms
Inputs
Number 12
Voltage and current at input, reset and feedback circuit 24.0 V, 5.0 mA
Galvanic isolation no
Signal level at "0" -3 - +5 V DC
Signal level at "1" 15 - 30 V DC
Min. pulse duration 16 ms
Pulse suppression 0.6 ms
Maximum input delay 4 ms
Test pulse outputs
Number of test pulse outputs 4
Voltage and current, 24 V 0.1 A
Off time during self test 5 ms
Galvanic isolation no
Short circuit-proof yes
Semiconductor outputs
Number 4
Switching capability
voltage 24 V
current 2 A
power 48 W
Max. capacitive load 1 µF
External supply voltage 24.0 V
Voltage tolerance -15 %/+20 %
Max. duration of off time during self test 330 µs
Galvanic isolation yes
Short circuit-proof yes
Switch-off delay 30 ms
Residual current at "0" 0.5 mA
Signal level at "1" UB - 0.5 V DC bei 2 A
Configurable inputs/outputs (inputs or auxiliary out-
puts)
Number 8
Galvanic isolation no
