Pilz PNOZ X1 User Manual

PNOZ X1
Operating Manual PNOZ X1
19045-EN-10
| 15
Relay outputs
External contact fuse protection, auxiliary contacts
Max. melting integral 160 A²s
Blow-out fuse, quick 10 A
Blow-out fuse, slow 6 A
Blow-out fuse, gG 6 A
Circuit breaker 24 V AC/DC, characteristic B/C 6 A
Contact material AgCuNi + 0,2 µm Au
Conventional thermal current while loading sev-
eral contacts
Ith per contact at UB AC; AC1:240V,DC1:24V
Conv. therm. current with 1 contact 6 A
Conv. therm. current with 2 contacts 6 A
Conv. therm. current with 3 contacts 5 A
Ith per contact at UB DC; AC1:240V,DC1:24V
Conv. therm. current with 1 contact 6 A
Conv. therm. current with 2 contacts 6 A
Conv. therm. current with 3 contacts 5 A
Times
Switch-on delay
With automatic start typ. 60 ms
With automatic start max. 120 ms
With manual start typ. 50 ms
With manual start max. 120 ms
Delay-on de-energisation
With E-STOP typ. 55 ms
With E-STOP max. 90 ms
With power failure typ. 55 ms
With power failure max. 90 ms
Recovery time at max. switching frequency 1/s
After E-STOP 150 ms
After power failure 150 ms
Supply interruption before de-energisation 20 ms
Environmental data
Climatic suitability EN 60068-2-78
Ambient temperature
Temperature range -10 - 55 °C
Storage temperature
Temperature range -40 - 85 °C
Climatic suitability
Humidity 93 % r. h. at 40 °C
Condensation during operation Not permitted
EMC EN 60947-5-1, EN 61000-6-2, EN 61326-3-1

Pilz PNOZ X1 Specifications

General

Type	Safety Relay
Supply Voltage	24 VDC
Auxiliary Contacts	1 N/C
Width	45 mm
Mounting	DIN Rail
Number of safety contacts	2
Stop Category	0
Height	87 mm
Depth	121 mm
Rated current	6 A
Protection class	IP20
Safety Contacts	2 N/O
Operating Temperature Range	-10°C to +55°C
Weight	200 g
