PNOZ X1
Operating Manual PNOZ X1
19045-EN-10
| 16
Environmental data
Vibration
In accordance with the standard EN 60068-2-6
Frequency 10 - 55 Hz
Amplitude 0,35 mm
Airgap creepage
In accordance with the standard EN 60947-1
Overvoltage category III
Pollution degree 2
Rated insulation voltage 250 V
Rated impulse withstand voltage 6 kV
Protection type
Housing IP40
Terminals IP20
Mounting area (e.g. control cabinet) IP54
Mechanical data
Mounting position Any
Mechanical life 10,000,000 cycles
Material
Bottom PPO UL 94 V0
Front ABS UL 94 V0
Top PPO UL 94 V0
Connection type Screw terminal
Mounting type Fixed
Conductor cross section with screw terminals
1 core flexible 0,2 - 4 mm², 24 - 10 AWG
2 core with the same cross section, flexible with
crimp connectors, no plastic sleeve 0,2 - 2,5 mm², 24 - 14 AWG
2 core with the same cross section, flexible without
crimp connectors or with TWIN crimp connectors 0,2 - 2,5 mm², 24 - 14 AWG
Torque setting with screw terminals 0,6 Nm
Stripping length with screw terminals 8 mm
Dimensions
Height 87 mm
Width 22,5 mm
Depth 121 mm
Weight 175 g
Where standards are undated, the 2020-07 latest editions shall apply.
