Pilz PNOZ X3 User Manual

PNOZ X3
Operating Manual PNOZ X3
20547-EN-10
22
Inputs 774314 774315 774316
Max. overall cable resist-
ance Rlmax
Single-channel at UB
DC 150 Ohm 150 Ohm 150 Ohm
Single-channel at UB
AC 180 Ohm 180 Ohm 180 Ohm
Dual-channel with de-
tection of shorts across
contacts at UB DC 15 Ohm 15 Ohm 15 Ohm
Dual-channel with de-
tection of shorts across
contacts at UB AC
30 Ohm 30 Ohm 30 Ohm
Semiconductor outputs 774314 774315 774316
Number 1 1 1
Voltage 24 V 24 V 24 V
Current 20 mA 20 mA 20 mA
External supply voltage 24 V 24 V 24 V
Voltage tolerance -20 %/+20 % -20 %/+20 % -20 %/+20 %
Relay outputs 774314 774315 774316
Number of output con-
tacts
Safety contacts (N/O),
instantaneous 3 3 3
Auxiliary contacts (N/C) 1 1 1
Max. short circuit current
IK
1 kA 1 kA 1 kA
Utilisation category
In accordance with the
standard EN 60947-4-1 EN 60947-4-1 EN 60947-4-1
Utilisation category of
safety contacts
AC1 at 240 V 240 V 240 V
Min. current 0,01 A 0,01 A 0,01 A
Max. current 8 A 8 A 8 A
Max. power 2000 VA 2000 VA 2000 VA
DC1 at 24 V 24 V 24 V
Min. current 0,01 A 0,01 A 0,01 A
Max. current 8 A 8 A 8 A
Max. power 200 W 200 W 200 W

Pilz PNOZ X3 Specifications

General

Supply Voltage	24 V DC
Contacts	3 N/O, 1 N/C
Width	45 mm
Depth	121 mm
Safety Category	4
Performance Level	e
SILCL	3
Rated Current	6 A
Contact Material	AgSnO2
Protection Class	IP20
Weight	200 g
Stop Category	0
Operating Temperature Range	-10°C to 55°C
