Pilz PNOZ X3 User Manual

PNOZ X3
Operating Manual PNOZ X3
20547-EN-10
25
Times 774314 774315 774316
Recovery time at max.
switching frequency 1/s
After E-STOP 50 ms 50 ms 50 ms
After power failure 100 ms 100 ms 100 ms
Waiting period with a
monitored start
300 ms 300 ms 300 ms
Min. start pulse duration
with a monitored start
30 ms 30 ms 30 ms
Supply interruption before
de-energisation
20 ms 20 ms 20 ms
Simultaneity, channel 1
and 2 max.
∞ ∞ ∞
Environmental data 774314 774315 774316
Climatic suitability EN 60068-2-78 EN 60068-2-78 EN 60068-2-78
Ambient temperature
Temperature range -20 - 55 °C -20 - 55 °C -20 - 55 °C
Storage temperature
Temperature range -40 - 85 °C -40 - 85 °C -40 - 85 °C
Climatic suitability
Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C 93 % r. h. at 40 °C
Condensation during op-
eration
Not permitted Not permitted Not permitted
EMC EN 12015, EN 12016, EN
60947-5-1, EN 61000-6-2,
EN 61326-3-1
EN 12015, EN 12016, EN
60947-5-1, EN 61000-6-2,
EN 61326-3-1
EN 12015, EN 12016, EN
60947-5-1, EN 61000-6-2,
EN 61326-3-1
Vibration
In accordance with the
standard EN 60068-2-6 EN 60068-2-6 EN 60068-2-6
Frequency 10 - 55 Hz 10 - 55 Hz 10 - 55 Hz
Amplitude 0,35 mm 0,35 mm 0,35 mm
Airgap creepage
In accordance with the
standard EN 60947-1 EN 60947-1 EN 60947-1
Overvoltage category III / II III / II III / II
Pollution degree 3 3 3
Rated insulation voltage 250 V 250 V 250 V
Rated impulse withstand
voltage
4 kV 4 kV 4 kV
Protection type
Housing IP40 IP40 IP40
Terminals IP20 IP20 IP20
Mounting area (e.g.
control cabinet)
IP54 IP54 IP54
Mechanical data 774314 774315 774316
Mounting position Any Any Any
Mechanical life 10,000,000 cycles 10,000,000 cycles 10,000,000 cycles

Pilz PNOZ X3 Specifications

General

Supply Voltage	24 V DC
Contacts	3 N/O, 1 N/C
Width	45 mm
Depth	121 mm
Safety Category	4
Performance Level	e
SILCL	3
Rated Current	6 A
Contact Material	AgSnO2
Protection Class	IP20
Weight	200 g
Stop Category	0
Operating Temperature Range	-10°C to 55°C
