Pilz PNOZ X3 User Manual

PNOZ X3
Operating Manual PNOZ X3
20547-EN-10
24
Relay outputs 774314 774315 774316
External contact fuse pro-
tection, auxiliary contacts
Max. melting integral 240 A²s 240 A²s 240 A²s
Blow-out fuse, quick 10 A 10 A 10 A
Blow-out fuse, slow 6 A 6 A 6 A
Blow-out fuse, gG 10 A 10 A 10 A
Circuit breaker 24 V
AC/DC, characteristic
B/C 6 A 6 A 6 A
Contact material AgSnO2 + 0,2 µm Au AgSnO2 + 0,2 µm Au AgSnO2 + 0,2 µm Au
Conventional thermal
current while loading
several contacts
774314 774315 774316
Ith per contact at UB AC;
AC1:240V,DC1:24V
Conv. therm. current
with 1 contact 8 A 8 A 8 A
Conv. therm. current
with 2 contacts 7,5 A 7,5 A 7,5 A
Conv. therm. current
with 3 contacts 6,5 A 6,5 A 6,5 A
Ith per contact at UB DC;
AC1:240V,DC1:24V
Conv. therm. current
with 1 contact 8 A 8 A 8 A
Conv. therm. current
with 2 contacts 8 A 8 A 8 A
Conv. therm. current
with 3 contacts
7 A 7 A 7 A
Times 774314 774315 774316
Switch-on delay
With automatic start
typ. 250 ms 250 ms 250 ms
With automatic start
max. 500 ms 500 ms 500 ms
With automatic start
after power on typ. 280 ms 280 ms 280 ms
With automatic start
after power on max. 550 ms 550 ms 550 ms
With monitored start
typ. 35 ms 35 ms 35 ms
With monitored start
max. 50 ms 50 ms 50 ms
Delay-on de-energisation
With E-STOP typ. 15 ms 15 ms 15 ms
With E-STOP max. 30 ms 30 ms 30 ms
With power failure typ. 50 ms 50 ms 50 ms
With power failure max. 70 ms 70 ms 70 ms

Pilz PNOZ X3 Specifications

General

Supply Voltage	24 V DC
Contacts	3 N/O, 1 N/C
Width	45 mm
Depth	121 mm
Safety Category	4
Performance Level	e
SILCL	3
Rated Current	6 A
Contact Material	AgSnO2
Protection Class	IP20
Weight	200 g
Stop Category	0
Operating Temperature Range	-10°C to 55°C
