4 Function description
4.1 Basic function of the safety laser scanner
The safety laser scanner monitors an area that is covered by the light beam emitted by the
safety laser scanner.
[1]
[2]
[3]
[4]
[5]
Fig.: Operating principle safety laser scanner
Legend
[1] Hazardous area
[2] Area covered by the laser beam
[3] Safety laser scanner
[4] Safety zone
[5] Warning zone
The area can be divided into a safety zone and a warning zone.
If an object or a person enters the warning zone, corresponding actions can be triggered
(e.g. switch on indicator light unit).
If an object or a person violates the safety zone, the OSSDs switch to an OFF state.
