Overview
Operating Manual PSEN sc B 5 Series
1004508-EN-02
8
2 Overview
The safety laser scanners of the PSEN sc B 5 Series are electrosensitive protective equip-
ment (ESPE type: 3) in accordance with EN 61496-3 for workspaces in which machines, ro-
bots, and automated systems could endanger the physical integrity of operators.
Unit features
} Detection capability: 70 mm
} LED display and display for status information
} Scan angle: 275°
} Infrared laser beams build up a 2-dimensional protected area
} Separation of the protected area in a safety zone and a warning zone
} max. 3 switchable zone sets [ 13] possible
} Enhanced availability by configurable multiple evaluation
} The safety laser scanner can be installed and operated overhead.
