Project configuration
Operating Manual PSEN sc B 5 Series
1004508-EN-02
18
5 Project configuration
5.1 Maintaining the safety distance
5.1.1 Horizontal application
A horizontal application has been achieved when the safety laser scanner is aligned at an
angle of max. 30° with the floor level.
[1]
[2]
[3]
[4]
Fig.: Schematic representation minimum distance from the start of the protected area to the hazard-
ous area
Legend
[1] Hazardous area
[2] Area covered by the laser beam
[3] Safety laser scanner
[4] Minimum distance to the hazardous area (corresponds max. to the operating
range of the safety laser scanner)
