Pilz PSEN sc B 5 Series User Manual

Project configuration
Operating Manual PSEN sc B 5 Series
1004508-EN-02
22
5.4 Installation of several adjacent safety laser scanners
When safety laser scanners have to be installed in an area, it must be ensured that an in-
terference between the safety laser scanners occur at a maximum for the duration of the
double rotation time (see
Technical details [ 66]).
This can be achieved by installing the safety laser scanner in various heights or inclination
or by an opaque object between two laser scanners.
} Change the height of the safety laser scanners
} Change the inclination of the safety laser scanners.
