Technical details
Operating Manual PSEN sc B 5 Series
1004508-EN-02
66
13 Technical details
General
Approvals CE, TÜV, cULus Listed
ESPE type 3
Sensor's mode of operation Optical
Resolutions 70 mm
Operating range
Warning zone 40 m
Safety zone 5,5 m
Number of simultaneously monitored safety zones 1
Number of simultaneously monitored zones 2
Number of zone configurations 3
Electrical data
Supply voltage
Voltage 24 V
Kind DC
Voltage tolerance -20 %/+30 %
Residual ripple DC 5 %
Power consumption 27 W
Protection class 3
Optical data
Diameter light spot on front plate 8 mm
Used wavelength range 905 nm
Laser class (DIN EN 60825-1) 1
Scan area 275°
Max. opening angle scanner 0,12°
Angle resolution 0,1°
Max. number multiple evaluation 16
Detectable remission area 1,8 - 1.000 %
Pulse duration 3 ns
Typical output power laser 8 mW
Inputs
Max. overall line capacitance Clmax 2.200 nF
Semiconductor outputs
OSSD safety outputs 2
Switching current per output 250 mA
Voltage drop at OSSDs 2 V
Times
Test pulse duration, safety outputs 300 µs
Response time t1 62 ms
Rotation time 30 ms
