Pilz PSEN sc B 5 Series User Manual

Technical details
Operating Manual PSEN sc B 5 Series
1004508-EN-02
67
Environmental data
Ambient temperature
Temperature range 0 - 50 °C
Storage temperature
Temperature range -20 - 70 °C
Climatic suitability
Humidity max. 95 %
Condensation during operation Not permitted
Vibration
In accordance with the standard EN 60068-2-6
Frequency 10 - 55 Hz
Amplitude 0,35 mm
Shock stress
In accordance with the standard EN 60068-2-27
Number of shocks 1000
Acceleration 10g
Duration 16 ms
Protection type
Housing IP65
Deviation from ideal flatness of the scan field at max.
operating range
50 mm
Mechanical data
Distance scanning plane to top edge 37,7 mm
Distance mirror rotational axis to the rear 52,5 mm
Connection type M12, 8-pin male connector
Material
Housing Aluminium
Top PC
Front screen PMMA
Max. torque setting
Fixing screw 3 Nm
Adjusting screw for angle of inclination 2,5 Nm
PSEN sc Memory 1 Nm
Dimensions
Height 152 mm
Width 102 mm
Depth 112,5 mm
Weight 1.530 g
Where standards are undated, the 2017-11 latest editions shall apply.

Pilz PSEN sc B 5 Series Specifications

General

Brand	Pilz
Model	PSEN sc B 5 Series
Category	Scanner
Language	English
