Function description
Operating Manual PSEN sc B 5 Series
1004508-EN-02
16
OSSD
Fig.: Timing diagram reset
4.7 Stationary hazardous area
Using the safety laser scanner, you can monitor a stationary hazardous area, e.g. the envir-
onment of a machine that is installed in a fixed position.
The monitored area can be divided into subsections, for which monitoring can be activated
and deactivated each.
[1]
[3]
[2]
Legend
[1] Hazardous area
[2] Configured zone 1, monitoring not activated
[3] Configured zone 2, monitoring not activated
