Project configuration
Operating Manual PSEN sc B 5 Series
1004508-EN-02
20
} When the safety laser scanner is to be placed at a height of H>300mm, creeping un-
derneath the safety zone must be excluded.
[1]
[2]
[3]
Legend
[1] Opening between the origin of the laser beam of the safety laser scanner and the
mounting area
[2] Scanning plane
[3] Height H between scanning plane and base area
CAUTION!
Risk of injury by reaching into the opening between safety laser scan-
ner and mounting area
Reaching into the opening between safety laser scanner and mounting area
can lead to injuries.
– Prevent any possibility of reaching into the opening
