PSS(1) ControlNet Adapter - Hardware Manual 7-1
Commissioning and Operation
Initial commissioning
Testing the components
Before operating the module, ensure the follwoing points are met:
• The module must be on a slot in the module rack on the standard bus of
the PSS.
How to install the module correctly is described in the “Installation
Manual” (Modular PSS Installation Manual).
• The physical bus structure must be installed correctly (correct bus
termination, no cable breaks...).
• The bus is configured correctly (refer also to the chapter “Configuration”
in the operating manual "ST SB ControlNet - Software Manual").
• The Net Address for the module must be set correctly.
Initialising the PSS
• Switch on the PSS
• Transfer the user program to the PSS
• Switch off the PSS.
Quick start
Once the above-mentioned points have been checked, the module is
ready to set into operation. Proceed as follows:
• Switch on the PSS.
• Wait until the module has run through its self-check and initialisation
phase. These processes may take a while.
When the module is ready for operation the LED for “module status” will
be green (refer also to the table in chapter 5 in the section “LEDs for
operating status and errors ”).
• Start communication via the ControlNet Scanner. Communication is
error-free when the corresponding LEDs for channel A and channel B
are green (refer also to the table in chapter 5 in the section “LEDs for
operating status and errors ”).
The module is ready for operation.
