Pilz PSS Series Hardware Manual

PSS(1) ControlNet Adapter - Hardware Manual 8-1
Technical Details
Electrical data
Power consumption Average: 380 mA
Interfaces ControlNet
(galvanically isolated) Network Adapter Port
Bus interface BNC-plug connector for channel A/B
Network Adapter Port 8-pin Western-socket
(RJ45)
ControlNet
Device type Adapter
Status indicator LED
Error indicator LED
Bit rate 5 MBit/s (fixed)
Net Address Set via rotary switches in the range
0 ... 99
D
Data length Scheduled Data Max. 256 words
Input data 128 words (configurable)
Output data 128 words (configurable)
Data length Unscheduled Data 64 words
Input data 32 words (configurable)
Output data 32 words (configurable)
Data transfer Word-by-word
Operating data
Terminating resistance Can be set
Communications structure Via standard function block
Module code BC20
H
XW-range standard bus 1024 words

Pilz PSS Series Specifications

General

Category	Safety Equipment
Manufacturer	Pilz
Safety Standards	EN ISO 13849-1, IEC 61508, IEC 62061
Series	PSS
Safety Integrity Level	SIL 3
Communication Interfaces	Ethernet, PROFIBUS, PROFINET
Operating Voltage	24 V DC
Operating Temperature	0°C to +55°C (typical), others depending on model
Storage Temperature	-20°C to +70°C (typical), others depending on model
Protection Class	IP20
Application	Industrial safety applications
