Pilz PSS Series Hardware Manual

Contents
2 PSS(1) ControlNet Adapter - Hardware Manual
Module 5-1
Front view 5-1
Cables and interfaces 5-2
ControlNet connections 5-2
ControlNet connection cable 5-2
Cable runs 5-2
Network Access Port 5-3
Conenction cable for the Network Access Port 5-3
Net Address 5-4
LEDs for operating and error status 5-5
LED "module status" 5-5
LED "
A
" and LED "
B
" (network status) 5-6
Installation and Configuration 6-1
Installing the module in the module rack 6-1
Configuration 6-1
Setting the Net Address 6-1
Bus termination 6-2
Commissioning and Operation 7-1
Initial commissioning 7-1
Testing the components 7-1
Initialising the PSS 7-1
Quick start 7-1
Error diagnostics 7-2
Operation 7-2
Technical Details 8-1

Pilz PSS Series Specifications

General

Category	Safety Equipment
Manufacturer	Pilz
Safety Standards	EN ISO 13849-1, IEC 61508, IEC 62061
Series	PSS
Safety Integrity Level	SIL 3
Communication Interfaces	Ethernet, PROFIBUS, PROFINET
Operating Voltage	24 V DC
Operating Temperature	0°C to +55°C (typical), others depending on model
Storage Temperature	-20°C to +70°C (typical), others depending on model
Protection Class	IP20
Application	Industrial safety applications
