Pinnacle Systems, Inc. TARGA 3000 Hardware & Software Installation

C-3Pinnacle Systems TARGA 3000
TARGA 3000 Pro Analog Breakout Box Only
General
Width -- 12.0" ( 19.0" w/rack mount bracket)
Height -- 3.5"
Depth -- 3.8"
Weight -- 2.5 lb. (1.0 Kg.)
Power Supply -- Power is suppled from T3000 digital tether cable
Input Current -- 300mA @ +12vDC
-- 150mA @ -12vDC
-- 500mA @ +5v DC
-- 300mA @ +3.3v DC
Ambient Temperature -- Operating at 0 to 40° C
Ambient Humidity -- Operating at 0 to 90% non-condensing
Mounting Option -- Detachable (bracket for mounting in a 19.0" wide rack)
Sampling Structure -- I.T.U. 656, 8 Bit, 4:2:2, Component
Sampling Frequency -- Y: 13.5 MHz
B-Y, R-Y: 6.75 MHz
Video Input
CV, Y/C -- 8 bit, 4:2:2 spatial resolution
-- Gain and offset controls
-- Saturation controls
-- CV input passes through a comb filter
*
CV 1.0 V p-p, 75 Ω, BNC
*
S-Video Y: 1.0V p-p
C: 627mV p-p
4-pin DIN
*Output levels are based on NTSC 100% white 75% amplitude fully saturated bars.
