C-6
Appendix C: TARGA 3000 Technical Specifications
TARGA 3000 Pro Digital Breakout Box Only
General
Width -- 2.2"
Height -- 3.7"
Depth -- 0.9"
Weight -- 2.5 oz. (0.34 Kg.)
Power Supply -- Power is suppled from T3000 digital tether cable
-- 1.8 watts typical
Ambient Temperature -- Operating at 0 to 40° C
Ambient Humidity -- Operating at 0 to 90% non-condensing
Video Input
Standards Conformance -- ITU-R BT.656; SMPTE 125M; 259M
SDI -- Input impedance at 75 Ω
-- Return loss less than 15dB from 5 MHz to 270 MHz
-- Resolution at 8/10 bits
-- Bit rate at 270 Mb/sec
Video Output
Standards Conformance -- ITU-R BT.656; SMPTE 125M; 259M
SDI -- Amplitude at 800 mV p-p,
±
10% into 75 Ω
-- Overshoot at ≤ 10%
-- Rise and fall times at 0.4 to 1.5 ns
-- Jitter ≤ 0.2 UI p-p total for all frequencies above 10 Hz
-- Resolution at 8/10 bits
-- Bit rate at 270 Mb/sec
