RCA cable (supplied with Multi-channel
processor controller unit)
Black
Blue
Blue
RCA cable
(supplied with
multi-channel
processor)
Multi-channel processor
controller unit
(e.g. AXM-P8000)
(Hide away unit)
Multi-channel processor
controller unit
(e.g. AXM-P8000)
(Display unit)
OPT.IN 2
Optical cable
(supplied with multi-channel
processor)
IP-BUS cable
(supplied with multi-channel processor)
Multi-channel processor
(e.g. DEQ-P8000)
(sold separately)
Connecting the System
En
11
English
Section
03
