When connecting to separately sold power amp
The display unit
20 cm (7-7/8 in.)
Blue/White
30 cm (12 in.)
To system control terminal of the power amp
(max. 300 mA 12 V DC).
Do not connect this lead to auto-antenna control
terminal.
15 cm (5-7/8 in.)
15 cm (5-7/8 in.)
RCA connector
Subwoofer output or non-fading output
(SUBWOOFER OUTPUT or NON-
FADING OUTPUT)
Front output
(FRONT OUTPUT)
Rear output
(REAR OUTPUT)
Connecting the System
En
16
Section
03
