Pioneer PDP-435PG User Manual

PDP-435PE
29
5678
56
7
8
C
D
F
A
B
E
CN4004 (R4) < ⇔ DIGITAL VIDEO ASSY > (1/2)
• Voltages
No. Signal Name I/O Signal Description Voltages at NTSC Signal Input
1 GND
−
GND
2 GND
−
GND
GND
−
GND
GND
−
GND
GND
−
GND
GND
−
GND
3
−
4
−
−
−
5 BA0 O
8bit video signal output (BLUE even number) 0-3.3V amplitude square wave
6 BA1 O
8bit video signal output (BLUE even number) 0-3.3V amplitude square wave
7 BA2 O
8bit video signal output (BLUE even number) 0-3.3V amplitude square wave
8 BA3 O
8bit video signal output (BLUE even number) 0-3.3V amplitude square wave
9 BA4 O
8bit video signal output (BLUE even number) 0-3.3V amplitude square wave
10 BA5 O
8bit video signal output (BLUE even number) 0-3.3V amplitude square wave
11 BA6 O
8bit video signal output (BLUE even number) 0-3.3V amplitude square wave
12 BA7 O
8bit video signal output (BLUE even number) 0-3.3V amplitude square wave
13 GND
−
GND
14 GND
−
GND
15
−
16
−
−
−
17 GA0 O
8bit video signal output (GREEN even number) 0-3.3V amplitude square wave
18 GA1 O
8bit video signal output (GREEN even number) 0-3.3V amplitude square wave
19 GA2 O
8bit video signal output (GREEN even number) 0-3.3V amplitude square wave
20 GA3 O
8bit video signal output (GREEN even number) 0-3.3V amplitude square wave
21 GA4 O
8bit video signal output (GREEN even number) 0-3.3V amplitude square wave
22 GA5 O
8bit video signal output (GREEN even number) 0-3.3V amplitude square wave
23 GA6 O
8bit video signal output (GREEN even number) 0-3.3V amplitude square wave
24 GA7 O
8bit video signal output (GREEN even number) 0-3.3V amplitude square wave
25 GND
−
GND
26 GND
−
GND
GND
−
GND
GND
−
GND
27
−
28
−
−
−
29 RA0 O
8bit video signal output (RED even number) 0-3.3V amplitude square wave
30 RA1 O
8bit video signal output (RED even number) 0-3.3V amplitude square wave
31 RA2 O
8bit video signal output (RED even number) 0-3.3V amplitude square wave
32 RA3 O
8bit video signal output (RED even number) 0-3.3V amplitude square wave
33 RA4 O
8bit video signal output (RED even number) 0-3.3V amplitude square wave
34 RA5 O
8bit video signal output (RED even number) 0-3.3V amplitude square wave
35 RA6 O
8bit video signal output (RED even number) 0-3.3V amplitude square wave
36 RA7 O
8bit video signal output (RED even number) 0-3.3V amplitude square wave
37
GND\
−
GND
38 DCLK O
Synchronous signal output (clock) 0-3.3V amplitude square wave (42.5MHz)
39 GND
−
GND
GND
−
GND
GND
−
GND
GND
−
GND
GND
−
GND
40 DEI O
Synchronous signal output (data enable)
0-3.3V amplitude square wave (positive polarity)
41 HDI O
Synchronous signal output (Horizontal sync.)
0-3.3V amplitude square wave (negative polarity)
42 VDI O
Synchronous signal output (Vertical sync.)
0-3.3V amplitude square wave (negative polarity)
43 FIELD O
FIELD control signal 0V DC
44 APL_DT
Not connected
−
−
−
45
−
46
−
47 BB0 O
8bit video signal output (BLUE odd number) 0-3.3V amplitude square wave
48 BB1 O
8bit video signal output (BLUE odd number) 0-3.3V amplitude square wave
49 BB2 O
8bit video signal output (BLUE odd number) 0-3.3V amplitude square wave
50 BB3 O
8bit video signal output (BLUE odd number) 0-3.3V amplitude square wave
51 BB4 O
8bit video signal output (BLUE odd number) 0-3.3V amplitude square wave
52 BB5 O
8bit video signal output (BLUE odd number) 0-3.3V amplitude square wave
53 BB6 O
8bit video signal output (BLUE odd number) 0-3.3V amplitude square wave
54 BB7 O
8bit video signal output (BLUE odd number) 0-3.3V amplitude square wave
55 GND
−
GND
56 GND
−
GND
57
−
−
−
−
58
