Pioneer PDP-435PG User Manual

PDP-435PE
73
5678
56
7
8
C
D
F
A
B
E
2
Remove the flat clamp and remove the wires.
1
Remove the two screws.
3
Remove the IR Holder.
4
Remove the three screws to remove the Front Chassis VL (43).
5
Remove the four screws.
6
Disconnect the two pin connectors.
7
Remove the two PCB spacers.
8
Remove the four edge card spacers.
9
Remove the 43 SCAN A and B Assy's.
43 SCAN A and B Assy's
3
43 Y DRIVE Assy
43 SCAN A Assy
43 SCAN B Assy
4
4
4
1
1
2
3
99
8
8
8
5
7
6 6
×2
×2
5
Flat Clamp
IR Holder
Front Chassi VL (43)
7
