PDP-435PE
91
5678
56
7
8
C
D
F
A
B
E
Ball No. No. Pin Name Function
AA25 151 AD5TXOUT3P Address LVDS signal output
Y25 152 AD5TXCLKOUTP Address LVDS signal output
W25 153 AD5TXOUT2P Address LVDS signal output
V25 154 AD5TXOUT1P Address LVDS signal output
U25 155 AD5TXOUT0P Address LVDS signal output
T25 156 SDITRST_N JTAG signal
R25 157 RESETX Reset input
P25 158 GND GND
N25 159 GPIO0_0 Microcomputer macro general-purpose port
M25 160 YSUSA_5 Y-Drive control signal output
L25 161 YSUSA_11 Y-Drive control signal output
K25 162 YSUSA_15 Y-Drive control signal output
J25 163 GND GND
H25 164 YSUSB_7 Y-Drive control signal output
G25 165 YSUSB_11 Y-Drive control signal output
F25 166 NC NC pin
E25 167 NC NC pin
D25 168 GND GND
C25 169 SCAN_11 Scan control signal output
B25 170 CSIORXD Communication with UCOM
B24 171 CSIOSCKI Communication with UCOM
B23 172 UARTTXD Communication with UCOM
B22 173 UARTRXD Communication with UCOM
B21 174 CSWR_N0 Communication with UCOM
B20 175 GND GND
B19 176 EXA9 Flash memory address bus
B18 177 EXA6 Flash memory address bus
B17 178 EXA0 Flash memory address bus
B16 179 GND GND
B15 180 EXDIO_6 Flash memory data bus
B14 181 EXDIO_12 Flash memory data bus
B13 182 RBI_9 B phase signal input of R video (ninth bit)
B12 183 RBI_4 B phase signal input of R video (fourth bit)
B11 184 GND GND
B10 185 GBI_7 B phase signal input of G video (seventh bit)
B9 186 GBI_1 B phase signal input of G video (first bit)
B8 187 BBI_5 B phase signal input of B video (fifth bit)
B7 188 GND GND
B6 189 HDI HD signal input
B5 190 RAI_4 A phase signal input of R video (fourth bit)
B4 191 GAI_9 A phase signal input of G video (ninth bit)
B3 192 GAI_3 A phase signal input of G video (third bit)
C3 193 GAI_2 A phase signal input of G video (second bit)
D3 194 VDDD33 3.3V power supply
E3 195 GAI_1 A phase signal input of G video (first bit)
F3 196 GAI_0 A phase signal input of G video (0 bit)
G3 197 NC NC pin
H3 198 XSUSB_14 X-Drive control signal output
J3 199 VDDIO 3.3V power supply
K3 200 XSUSB_8 X-Drive control signal output
PDG054A (DIGITAL VIDEO ASSY : IC5401)
• PDP ASIC IC4
Pin Function (4/10)
To Next Page
