PDP-435PE
92
1234
1234
C
D
F
A
B
E
Ball No. No. Pin Name Function
L3 201 XSUSB_2 X-Drive control signal output
M3 202 XSUSA_14 X-Drive control signal output
N3 203 XSUSA_8 X-Drive control signal output
P3 204 VDDIO 3.3V power supply
R3 205 XSUSA_0 X-Drive control signal output
T3 206 TEST1 Test signal input (Not used)
U3 207 VSSLA GND
V3 208 VSSLA GND
W3 209 VSSLA GND
Y3 210 VSSLA GND
AA3 211 VSSLA GND
AB3 212 VSSLA GND
AC3 213 VSSLA GND
AD3 214 VSSLA GND
AD4 215 VSSLA GND
AD5 216 VSSLA GND
AD6 217 VSSLA GND
AD7 218 VSSLA GND
AD8 219 VSSLA GND
AD9 220 VSSLA GND
AD10 221 VSSLA GND
AD11 222 VSSLA GND
AD12 223 VSSLA GND
AD13 224 VSSLA GND
AD14 225 VSSLA GND
AD15 226 VSSLA GND
AD16 227 VSSLA GND
AD17 228 VSSLA GND
AD18 229 VSSLA GND
AD19 230 VSSLA GND
AD20 231 VSSLA GND
AD21 232 VSSLA GND
AD22 233 VSSLA GND
AD23 234 VSSLA GND
AD24 235 VSSLA GND
AC24 236 VSSLA GND
AB24 237 VSSLA GND
AA24 238 VSSLA GND
Y24 239 VSSLA GND
W24 240 VSSLA GND
V24 241 VSSLA GND
U24 242 VSSLA GND
T24 243 SDITDO JTAG signal
R24 244 GPIO0_7 Microcomputer macro general-purpose port
P24 245 VDDIO 3.3V power supply
N24 246 YSUSA_0 Y-Drive control signal output
M24 247 YSUSA_6 Y-Drive control signal output
L24 248 YSUSA_12 Y-Drive control signal output
K24 249 YSUSB_0 Y-Drive control signal output
J24 250 VDDD33 3.3V power supply
PDG054A (DIGITAL VIDEO ASSY : IC5401)
• PDP ASIC IC4
Pin Function (5/10)
To Next Page
