PDP-435PE
93
5678
56
7
8
C
D
F
A
B
E
Ball No. No. Pin Name Function
H24 251 YSUSB_8 Y-Drive control signal output
G24 252 NC NC pin
F24 253 YSUSB_15 Y-Drive control signal output
E24 254 SCAN_3 Scan control signal output
D24 255 VDDD33 3.3V power supply
C24 256 SCAN_12 Scan control signal output
C23 257 SCAN_13 Scan control signal output
C22 258 SCAN_14 Scan control signal output
C21 259 SCAN_15 Scan control signal output
C20 260 VDDIO 3.3V power supply
C19 261 EXA8 Flash memory address bus
C18 262 EXA5 Flash memory address bus
C17 263 CLKD CLK input (60MHz)
C16 264 VDDIO 3.3V power supply
C15 265 EXDIO_7 Flash memory data bus
C14 266 EXDIO_13 Flash memory data bus
C13 267 RBI_8 B phase signal input of R video (eighth bit)
C12 268 RBI_3 B phase signal input of R video (third bit)
C11 269 VDDIO 3.3V power supply
C10 270 GBI_6 B phase signal input of G video (sixth bit)
C9 271 GBI_0 B phase signal input of G video (0 bit)
C8 272 BBI_4 B phase signal input of B video (fourth bit)
C7 273 VDDIO 3.3V power supply
C6 274 RAI_9 A phase signal input of R video (ninth bit)
C5 275 RAI_3 A phase signal input of R video (third bit)
C4 276 GAI_8 A phase signal input of G video (eighth bit)
D4 277 GAI_7 A phase signal input of G video (seventh bit)
E4 278 GAI_6 A phase signal input of G video (sixth bit)
F4 279 GAI_5 A phase signal input of G video (fifth bit)
G4 280 VCMP GND
H4 281 XSUSB_13 X-Drive control signal output
J4 282 XSUSB_11 X-Drive control signal output
K4 283 XSUSB_7 X-Drive control signal output
L4 284 XSUSB_1 X-Drive control signal output
M4 285 XSUSA_13 X-Drive control signal output
N4 286 XSUSA_7 X-Drive control signal output
P4 287 XSUSA_3 X-Drive control signal output
R4 288 ADRS_3 Address control signal output
T4 289 TESTAN Test signal input (Not used)
U4 290 VDDLA 3.3V power supply
V4 291 VDDLA 3.3V power supply
W4 292 VDDLA 3.3V power supply
Y4 293 VDDLA 3.3V power supply
AA4 294 VDDLA 3.3V power supply
AB4 295 VDDLA 3.3V power supply
AC4 296 VDDLA 3.3V power supply
AC5 297 VDDLA 3.3V power supply
AC6 298 VDDLA 3.3V power supply
AC7 299 VDDLA 3.3V power supply
AC8 300 VDDLA 3.3V power supply
PDG054A (DIGITAL VIDEO ASSY : IC5401)
• PDP ASIC IC4
Pin Function (6/10)
