PDP-435PE
94
1234
1234
C
D
F
A
B
E
Ball No. No. Pin Name Function
AC8 300 VDDLA 3.3V power supply
AC9 301 VDDLA 3.3V power supply
AC10 302 VDDLA 3.3V power supply
AC11 303 VDDLA 3.3V power supply
AC12 304 VDDLA 3.3V power supply
AC13 305 VDDLA 3.3V power supply
AC14 306 VDDBG 3.3V power supply
AC15 307 VDDLA 3.3V power supply
AC16 308 VDDLA 3.3V power supply
AC17 309 VDDLA 3.3V power supply
AC18 310 VDDLA 3.3V power supply
AC19 311 VDDLA 3.3V power supply
AC20 312 VDDLA 3.3V power supply
AC21 313 VDDLA 3.3V power supply
AC22 314 VDDLA 3.3V power supply
AC23 315 VDDLA 3.3V power supply
AB23 316 VDDLA 3.3V power supplyv
AA23 317 VDDLA 3.3V power supply
Y23 318 VDDLA 3.3V power supply
W23 319 VDDLA 3.3V power supply
V23 320 VDDLA 3.3V power supply
U23 321 VDDLA 3.3V power supply
T23 322 SDITDI JTAG signal
R23 323 GPIO0_6 Microcomputer macro general-purpose port
P23 324 GPIO0_2 Microcomputer macro general-purpose port
N23 325 YSUSA_1 Y-Drive control signal output
M23 326 YSUSA_7 Y-Drive control signal output
L23 327 YSUSA_13 Y-Drive control signal output
K23 328 YSUSB_1 Y-Drive control signal output
J23 329 YSUSB_5 Y-Drive control signal output
H23 330 YSUSB_9 Y-Drive control signal output
G23 331 VCMP GND
F23 332 SCAN_0 Scan control signal output
E23 333 SCAN_4 Scan control signal output
D23 334 SCAN_7 Scan control signal output
D22 335 SCAN_8 Scan control signal output
D21 336 SCAN_9 Scan control signal output
D20 337 EXA11 Flash memory address bus
D19 338 EXA19 Flash memory address bus
D18 339 EXA4 Flash memory address bus
D17 340 EXDIO_0 Flash memory data bus
D16 341 EXDIO_4 Flash memory data bus
D15 342 EXDIO_8 Flash memory data bus
D14 343 EXDIO_14 Flash memory data bus
D13 344 RBI_7 B phase signal input of R video (seventh bit)
D12 345 RBI_2 B phase signal input of R video (second bit)
D11 346 GBI_9 B phase signal input of G video (ninth bit)
D10 347 GBI_5 B phase signal input of G video (fifth bit)
D9 348 BBI_9 B phase signal input of B video (ninth bit)
D8 349 BBI_3 B phase signal input of B video (tenth bit)
PDG054A (DIGITAL VIDEO ASSY : IC5401)
• PDP ASIC IC4
Pin Function (7/10)
