Ball No. No. Pin Name Function
J22 400 VDDHL 3.3V power supply
H22 401 VSSD15 GND
G22 402 YSUSB_12 Y-Drive control signal output
F22 403 SCAN_1 Scan control signal output
E22 404 SCAN_5 Scan control signal output
E21 405 SCAN_6 Scan control signal output
E20 406 VSS15 GND
E19 407 EXA18 Flash memory address bus
E18 408 EXA3 Flash memory address bus
E17 409 EXDIO_1 Flash memory data bus
E16 410 VSS15 GND
E15 411 EXDIO_9 Flash memory data bus
E14 412 EXDIO_15 Flash memory data bus
E13 413 RBI_6 B phase signal input of R video (sixth bit)
E12 414 CLKS CLK input (85MHz)
E11 415 VSS15 GND
E10 416 GBI_4 B phase signal input of G video (fourth bit)
E8 418 BBI_2 B phase signal input of B video (second bit)
E9 417 BBI_8 B phase signal input of B video (eighth bit)
E7 419 VSS15 GND
E6 420 RAI_7 A phase signal input of R video (seventh bit)
F6 421 RAI_6 A phase signal input of R video (sixth bit)
G6 422 APL_DT APL value trigger input
H6 423 VDD15 1.5V power supply
J6 424 VBB VBB power monitor in the DRAM
K6 425 XSUSB_5 X-Drive control signal output
L6 426 VDDD15 1.5V power supply
M6 427 XSUSA_11 X-Drive control signal output
N6 428 XSUSA_5 X-Drive control signal output
P6 429 VDD15 1.5V power supply
R6 430 ADRS_1 Address control signal output
T6 431 TESTCN Test signal input (Not used)
U6 432 VDDL15 1.5V power supply
V6 433 VDDLA 3.3V power supply
W6 434 VDDLA 3.3V power supply
Y6 435 VDDL15 1.5V power supply
AA6 436 VDDLA 3.3V power supply
AA7 437 VDDLA 3.3V power supply
AA8 438 VDDL15 1.5V power supply
AA9 439 VDDLA 3.3V power supply
AA10 440 VDDLA 3.3V power supply
AA11 441 VDDL15 1.5V power supply
AA12 442 VDDLA 3.3V power supply
AA13 443 VDDLA 3.3V power supply
AA14 444 VDDLA 3.3V power supply
AA15 445 VDDLA 3.3V power supply
AA16 446 VDDL15 1.5V power supply
AA17 447 VDDLA 3.3V power supply
AA18 448 VDDLA 3.3V power supply
AA19 449 VDDL15 1.5V power supply
PDG054A (DIGITAL VIDEO ASSY : IC5401)
• PDP ASIC IC4
Pin Function (9/10)
