PDP-436SXE
66
1234
1234
C
D
F
A
B
E
¶ SIG-Mode Table
The signal mode is displayed in four charecters:
1st and 2nd charecters : Resolutin of the input signal ( numerics for the video signals, and alphabetics for the PC signals )
3rd and 4th charecters : Grouping of the V frequencies (refresh rate)
5th charecter : Selection of the screen size by the user is displayed.
SIG-Mode table for video signals (resolutions and V frequencies)
Selection of the screen size by the user is displayed.
1st and 2nd 3rd and 4th Signal Type Fv (Hz) Fh (kHz)
10
50 SDTV*625i 50.000 15.625
60 SDTV*525i 60.000 15.750
12 60 SDTV*525i (PAL60) 60.000 15.750
20
50 SDTV*625p 50.000 31.250
60 SDTV*525p 60.000 31.500
30
50 HDTV*1125i 50.000 28.125
60 HDTV*1125i 60.000 33.750
40
50 HDTV*750p 50.000 37.500
60 HDTV*750p 60.000 45.000
50 24 HDTV*1125p 24.000 27.000
5th Description on GUI
1 4:3
2 FULL(FULL1)
3 ZOOM
4 CINEMA
5 WIDE
6 FULL 14:9
7 CINEMA 14:9
8 FULL2
