Pioneer PDP-436SXE - Page 81

PDP-436SXE
81
5678
56
7
8
C
D
F
A
B
E
1. SYNC DET(+)
Only for the technical use.
6 INITIALIZE mode
¶ Operation items
No.
Function/Display Content RS-232C
1 SYNC DET(+) Only for the technical use. −
2 SG MODE ⇔ Paired SG_MODE with SG_PATTERN. Select SG Route. −
3 SG PATTERN ⇔ Paired SG_MODE with SG_PATTERN. Select SG Pattern. −
4 SIDE MASK LEVEL(+) Adjust Side Mask Color(R,G,B).
BSL
GSL
RSL
5 FINAL SETUP(+) Initialize flash memories on virgin product status FST
6 SR+ ⇔ Select SR+ mode or UART SELECT mode. −
7 UART SELECT ⇔ Select boud Rate on RS-232C Communication −
8 −
HDMI INTR POSITION(+) Only for the technical use. −
1
123456789
10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
I N I T I
S G M A –A N M V D E C – YO D E < = >
EA L I Z – 1 1V D 1 6 0 1 – N T V – J H S 6
2. SG MODE
The route of the Test Signal from the MVDEC is chosen by this function.
After setting this function, SG pattern should be set.
No. Display Function
1 SG OFF SG is set to OFF
2 DIG MVDEC YCBCR Digital output (YCbCr)
3 ANA MVDEC Y Analog output to the Videio SW (Y)
4 ANA MVDEC RGB SCART
5 ANA AD YCBCR Analog output to the RGB SW (YCbCr)
6 ANA AD RGB Analog output to the RGB SW (RGB)
