PDP-506PE
1. CONTRAST OF MISCELLANEOUS PARTS
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
Reference Nos. indicate the pages and Nos. in the service manual for the base model.
NOTES:
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
560
47k
0.5
1
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
5.62k RN1/4PC F562 x 10
1
5621
PDP-506PE/WYVIXK, PDP-506PG/TLDPFT, PRO-506PU/KUCXC and PDP-506PE/WYVI are constructed the same
except for the following :
CONTRAST TABLE
Part No.
PDP-506PE
WYVI
Ref. No.
Symbol and Description
Remarks
Mark
PDP-506PG
TLDPFT
PDP-506PE
WYVIXK
PCB ASSY
P17 - 1 NSP 50 X DRIVE ASSY AWV2257 AWV2257 AWV2209 AWV2209
50 X DRIVE ASSY AWW1075 AWW1075 AWW1020 AWW1020
P17 - 4 50 Y DRIVE ASSY AWV2258 AWV2258 AWV2210 AWV2210
PACKING
P9 - 1 > Power Cord ADG1214 ADG1214 Not used ADG1215
P9 - 4 Polyethlene Bag-S AHG1338 AHG1326 ADG1338 AHG1348
P9 - 5 NSP Catalogue Bag AHG1340 Not used Not used AHG1347
P9 - 6 NSP Warranty card ARY1114 ARY1114 Not used ARY1123
P9 - 7 Ferrite Core ATX1039 ATX-1039 ATX-1039 Not used
P9 - 8 Pad (50T-L) AHA2427 AHA2451 AHA2427 AHA2459
P9 - 9 Pad (50T-R) AHA2428 AHA2452 AHA2428 AHA2460
P9 - 10 Pad (50B-L) AHA2429 AHA2453 AHA2429 AHA2461
P9 - 11 Pad (50B-R) AHA2430 AHA2454 AHA2430 AHA2462
P9 - 12 Power Cord Case AHC1073 AHC1067 AHC1073 Not used
P9 - 13 Under Carton (50) AHD3344 Not used AHD3344 Not used
P9 - 13 Under Carton (506) Not used AHD3371 Not used Not used
P9 - 13 Under Carton (506PU) Not used Not used Not used AHD3379
P9 - 14 Upper Carton (506PE) AHD3345 AHD3372 Not used Not used
P9 - 14 Upper Carton (506PG) Not used Not used AHD3420 Not used
P9 - 14 Upper Carton (506EL) Not used Not used Not used AHD3381
P9 - 15 Mirror Mat AHG1284 AHG1327 AHG1284 AHG1352
P9 - 16 Caution Card ARM1232 ARM1232 ARM1232 ARM1239
REAR SECTION
P11 - 6 NSP Name Label (50PE) AAL2661 AAL2675 Not used Not used
P11 - 6 NSP Name Label (506PG) Not used Not used AAL2711 Not used
P11 - 6 NSP Name Label (506EL) Not used Not used Not used AAL2677
P11 - 7 Bolt Caution Label AAX3117 AAX3005 AAX3117 AAX3075
P11 - 8 AC Label PE AAX3194 AAX3194 Not used Not used
FRONT SECTION
P13 - 1 Front Case Assy (506PE) AMB2861 AMB2861 AMB2861 Not used
P13 - 1 Front Case Assy (506EL) Not used Not used Not used AMB2857
P13 - 3 Badge AAM1098 AAM1098 AAM1098 Not used
P13 - 3 Elite Badge Not used Not used Not used AAM1102
CHASSIS SECTION (2/2)
P17 - 17 6P Housing Wire (J109) ADX3118 ADX3118 ADX3118 ADX3132
P17 - 18 12P Housing Wire (J110) ADX3119 ADX3119 ADX3119 ADX3133
P17 - 20 3P Housing Wire (J113) ADX3122 ADX3122 ADX3122 ADX3136
PRO-506PU
KUCXC
Note: For PCB ASSEMBLIES, Refer to “ CONTRAST OF PCB ASSEMBLIES ”.
