234

PDP-506PE

AWV2210 and AWZ2258 are constructed the same except for the following :

Mark

Symbol and Description

Part No.

AWV2258 AWV2210

Remarks

[50 Y RESONANCE BLOCK]

IC2101 AXF1142 AXF1155

C2103 ACG1112 ACG1088

(0.22UF/250V) (0.1UF/250V)

C2107, C2108 ACG1112 Not used

(0.22UF/250V)

C2131- C2134, C2136 ACE1168 ACE1178

[50 Y SUS BLOCK]

C2271 ACG1124 ACG1118

(0.1UF/100V) (0.33UF/100V)

C2272 ACG1124 Not used

(0.1UF/100V)

CONTRAST OF PCB ASSEMBLIES

• 50 Y DRIVE ASSY

AWW1020 and AWW1075 are constructed the same except for the following :

Mark

Symbol and Description

Part No.

AWW1075 AWW1020

Remarks

[50 X RESONANCE BLOCK]

IC1101 AXF1142 AXF1155

C1101 ACG1112 ACG1088

(0.22 UF/250V) (0.1UF/250V)

C1106 - C1110 Not used ACE1178

C1112, C1113 ACG1112 Not used

(0.22UF/250V)

C1161 - C1164, C1166 ACE1168 Not used

• 50 X DRIVE ASSY
