4. RS-232C command for module microcomputer
Command
Name
Function
Effective only in
Factory mode
Remarks
A
ABL
∗∗∗
ABL ADJUSTMENT
Adjusting the upper limit of the power ?
AMT
S00 AUDIO MUTE OFF
Turning off the audio muting
S01 AUDIO MUTE ON
Turning on the audio muting
APW
S00 APL WB FUNCTION:OFF
WB correction interlocked with APL: OFF ?
S01 APL WB FUNCTION:ON
WB correction interlocked with APL: ON ?
B
BAL
∗∗∗
BALANCE ADJUSTMENT
Audio balance adjustment
BAS
∗∗∗
BASS ADJUSTMENT
Audio bass adjustment
BCP BACKUP COPY
Copying the backup data in the EEPROM ?
C
CBU CLEAR BACKUP
Clearing backup data ?
CHM CLEAR HOUR METER
Clearing data of the hour meter ?
Used only when the panel is replaced
CPC CLEAR POWER ON COUNT
Clearing power-on count data ?
Used only when the power unit is replaced
CPD CLEAR POWER DOWN
Clearing power-down information ?
Used only when the panel is replaced
CPM CLEAR PLUSE METER
Clearing data of the pulse meter ?
Used only when the panel is replaced
CSD CLEAR SHUT DOWN
Clearing shutdown information ?
Used only when the panel is replaced
D
DRV
S00 DRIVE OFF
Main power off
S01 DRIVE ON
Main power on
E
ESV
S00 POWER CONTROL NORMAL
Setting Power Consumption mode to 4-split normal curve
S01 POWER CONTROL MODE1
Setting Power Consumption mode to 2-split normal curve
S02 POWER CONTROL MODE2
Setting Power Consumption mode to 2-split power-saving curve
S10 POWER CONTROL NORMAL
Setting Power Consumption mode to 4-split normal curve (domestic)
S11 POWER CONTROL MODE1
Setting Power Consumption mode to 2-split normal curve (domestic)
S12 POWER CONTROL MODE2
Setting Power Consumption mode to 2-split power-saving curve (domestic)
F
FAJ FINISH ADJUSTMENT
Determining the flag of the HD DIGITAL Assy adjustment in "adjustment is completed"
?
?
FAN FACTRY NO
FAY FACTRY YES
Entering Factory mode Turning the mask setting off
FCS
S00 FOCUS OFF
Turning the FOCUS function off
S01 FOCUS ON
Turning the FOCUS function on
M
MKC
S00 MASK COMBINATION OFF
MASK off
S01 MASK COMBINATION 01
H ramp (slant 1) M ?
S02 MASK COMBINATION 02
H ramp (slant 4) M ?
S03 MASK COMBINATION 03
Slanting ramp M ?
S04 MASK COMBINATION 04
30 for aging ?
S05 MASK COMBINATION 05
05 for aging ?
S06 MASK COMBINATION 06
Erasing afterimage 1 ?
S07 MASK COMBINATION 07
Erasing afterimage 2 (RGB: zigzag, V: reverse) ?
S08 MASK COMBINATION 08
White (change in luminance level) ?
S09 MASK COMBINATION 09
PEAK SEEK RASTER ?
MKS
S00 MASK SINGLE OFF
MASK OFF
S01 MASK SINGLE 1
H ramp (slant 1) ?
S02 MASK SINGLE 2
H ramp (slant 4) ?
S03 MASK SINGLE 3
V ramp (slant 1) ?
S04 MASK SINGLE 4
Slanting ramp ?
