Pioneer PDP-506PG User Manual

PDP-506PE
46
1234
1234
C
D
F
A
B
E
Command
Name
Function
Effective only in
Factory mode
Remarks
MKS
S05 MASK SINGLE 5
Window(Hi=870Lo=102)
?
S06 MASK SINGLE 6
Window(Hi=1023Lo=102)
?
S07 MASK SINGLE 7
Window(Hi=1023)
?
S08 MASK SINGLE 8
Window(Hi=1023)4%
?
S09 MASK SINGLE 9
Window(Hi=1023)1.25%
?
S10 MASK SINGLE 10
Window(1/7LINE)
?
S11 MASK SINGLE 11
STRIPE(MGT/GRN)
?
S12 MASK SINGLE 12
STRIPE(GRN/MGT)
?
S13 MASK SINGLE 13
B & W, checker (1 line)
?
S14 MASK SINGLE 14
B & W, checker (2 lines)
?
S15 MASK SINGLE 15
B & W, checker (4 lines)
?
S16 MASK SINGLE 16
B & W, checker (8 lines)
?
S17 MASK SINGLE 17
COLOR BAR
?
S18 MASK SINGLE 18
Slanting lines
?
S19 MASK SINGLE 19
Red & black, checker (1 line)
?
S20 MASK SINGLE 20
Red & black, checker (2 lines)
?
S21 MASK SINGLE 21
Red & black, checker (4 ines)
?
S22 MASK SINGLE 22
Red & black, checker (8 lines)
?
S23 MASK SINGLE 23
RGB zigzag, V reverse
?
S24 MASK SINGLE 24
SUS 2000 pulses (black raster)
?
S25 MASK SINGLE 25
Window(Hi=870Lo=102) PATTAN3
?
S26 MASK SINGLE 26
Window(Hi=1023Lo=102) PATTAN3
?
S27 MASK SINGLE 27
Window(Hi=1023) Pattern 3
?
S28 MASK SINGLE 28
Window(Hi=1023)4% Pattern 3
?
S29 MASK SINGLE 29
Window(Hi=1023)1.25% Pattern 3
?
S30 MASK SINGLE 30
Window(1/7LINE) Pattern 3
?
S51 MASK SINGLE 51
Raster - White
?
S52 MASK SINGLE 52
Raster - Red
?
S53 MASK SINGLE 53
Raster - Green
?
S54 MASK SINGLE 54
Raster - Blue
?
S55 MASK SINGLE 55
Raster - Black
?
S56 MASK SINGLE 56
Raster - Cyan
?
S57 MASK SINGLE 57
Raster - Magenta
?
S58 MASK SINGLE 58
Raster - Yellow
?
S59 MASK SINGLE 59
Raster - Cyan 460 :W
?
S60 MASK SINGLE 60
Raster - Green 774 :W
?
S61 MASK SINGLE 61
Raster - Gray 912 :W
?
S62 MASK SINGLE 62
Raster - Yellow egg color: W
?
S63 MASK SINGLE 63
Raster - Beige: W
?
S64 MASK SINGLE 64
Raster - Sky color: W
?
S65 MASK SINGLE 65
Raster - Pale purple: W
?
S66 MASK SINGLE 66
Raster - Magenta 54 :W
?
S67 MASK SINGLE 67
Raster - Red 588
?
S68 MASK SINGLE 68
Red 1023 + α
?
S69 MASK SINGLE 69
Green 1023 + α
?
S70 MASK SINGLE 70
Blue 1023 + α
?
S71 MASK SINGLE 71
Red 588 + α
?
S72 MASK SINGLE 72
Green 588 + α
?
S73 MASK SINGLE 73
Blue 588 + α
?
