Pioneer PDP-506PG User Manual

PDP-506PE
51
5678
56
7
8
C
D
F
A
B
E
Data Arrangement
Data
Length
Output Example
ECO 3Byte QIP
1 SERIAL 15Byte _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
2 HOUR METER 8Byte 00000000
3 BACKUP HR MTR 8Byte 00000000
4 PON COUNTER 8Byte 00000000
CS 2Byte 94
Data Arrangement
Data
Length
Output Example
ECO 3Byte QAJ
1 V-SUS adjustment value 3Byte 128
2 V-OFT adjustment value 3Byte 128
3 V-RST-P adjustment value 3Byte 128
4 XSB adjustment value 3Byte 128
5 YSB adjustment value 3Byte 128
6 YTG adjustment value 3Byte 128
7 YTW adjustment value 3Byte 128
8 RSW adjustment value 3Byte 128
9 R-RIVISE setting value 1Byte 0
10 G-RIVISE setting value 1Byte 0
11 B-RIVISE setting value 1Byte 0
CS 2Byte B7
Command
Format
Effective Operation
Modes
Function Remarks
[QIP] All operations To acquire data on operations of the panel Return data: 3 (ECO)+39(DATA)+2(CS)=44Byte
7 Acquisition of other data on the panel • • • [QIP]
The command QIP is for acquiring data other than those available with QS1 (data necessary before turning the power on)
and QS2 (data to inform of operational status change).
Note : The real product serial number is displayed in "SERIAL".
Command
Format
Effective Operation
Modes
Function Remarks
[QAJ] All operations To acquire data on operations of the panel Return data: 3 (ECO)+27(DATA)+2(CS)=32Byte
7 Acquisition of panel adjustment data (common data) • • • [QAJ]
The command QAJ is for acquiring data on the panel's factory-preset items that are common to the main unit and that
share the same memory.
