PDP-506PE
50
1234
1234
C
D
F
A
B
E
Data Arrangement
Data
Length
Output Example
ECO 3Byte QS2
1 Notification of mode shifting to STB 1Byte 1
2 Flag for adjustment of the main unit 1Byte 0
3 Flag for adjustment-data backup 1Byte 0
4 "1st PD" data 1Byte 0
5 "2nd PD" data 1Byte 0
6 Reservation 3Byte ∗∗∗
7 Temperature data (TEMP 1) 3Byte 128
8 SD main data 1Byte 0
9 SD subdata 1Byte 0
10 Operation status induced by SD 1Byte 0
11 Data from the hour meter 8Byte 00000259
12 MASK indication 1Byte 0
CS 2Byte 4A
¶ Notification of mode
shifting to Standby
0
Entering Standby
mode failed
1
Entering Standby
mode succeeded
¶ Adjustment of the
main unit
0
Adjustment completed
1
Adjustment not
completed
¶ Adjustment-data
backup
0 With backup data
1 No data
¶ PD data
0 No PD data
1 Not used
2 POWER
3 SCAN
4 SCN-5V
5 Not used
6 Y-DCDC
7 Y-SUS
8 ADRS
9 X-DRV
A X-DCDC
B X-SUS
C Not used
D SQ-IC
E Not used
F Specification inability
¶ SD main data
0 No SD
1 SQ-IC
2 MDU-IIC
3 RST2
4
Panel having high
temperature
5
Short-circuited
speaker
¶ Operation status
induced by SD
0 Normal
1 Relay-off completed
2
During warning
indication
¶ MASK indication
0 MASK-OFF
1 MASK-ON
Command
Format
Effective Operation
Modes
Function Remarks
[QS2] All operations
To acquire data on operations of the panel
Return data: 3 (ECO)+23(DATA)+2(CS)=28Byte
7 Acquisition of panel operation data • • • [QS2]
The command QS2 is for acquiring data on the panel's operations. Basically, this command is used for the module's
microcomputer to inform the main unit's microcomputer of changes in panel operation.
Note : "00000259" of "Data from the hour meter" means 2 hours 59 minuts.
¶ SD subdata (IIC)
0 No SD subdata
1 EEPROM
2 BACKUP
3 DAC
4 VOL IC
5 DVI
