Pioneer PDP-506PG User Manual

PDP-506PE
84
1234
1234
C
D
F
A
B
E
1
Remove the two screws.
2
Remove the panel holder V1 (50) and V2 (50)s.
(Unhook the six hooks.)
3
Release the housing wire.
4
Remove the three screws.
5
Remove the front chassis VL (50).
6
Remove the four screws.
7
Disconnect the two pin connectors.
8
Unhook the seven PCB spacers.
9
Remove the 50 SCAN A and B Assys.
50 SCAN A and B Assys
6
1
2 2
3
1
Panel holder V1 (50)
Hook
×3 Hook ×3
Panel holder V2 (50)
5
Front chassis VL (50)
4
4
4
50 Y DRIVE Assy
50 SCAN B
Assy
50 SCAN A
Assy
7 7
8
8
8
8
×2
×2
×2
×2
66
9
9
8
