53
En
Useful Adjustment Settings
11
English
Selecting an input signal type
After connecting to the INPUT 1, INPUT 2, or INPUT 3 terminal,
specify the type of video signals to be received from the
connected equipment. For the type of the signals, see the
operation manual that came with the connected equipment.
Before starting the menu, press INPUT 1, INPUT 2, or INPUT 3
on the remote control unit or press INPUT on the Plasma
Television to select an input source.
1 Press HOME MENU.
2 Select “Option” ( / then ENTER).
3 Select “Input Select” ( / then ENTER).
4 Select a signal type ( / then ENTER).
• For INPUT1, you can select “Video” or “RGB”.
• For INPUT2, you can select “Video”, “S-Video” or
“COMPONENT”.
• For INPUT3, you can select “Video”, “S-Video”, or “RGB”.
5 Press HOME MENU to exit the menu.
NOTE
• If no image appears or images appear in inappropriate
colours, specify another video signal type.
• For the signal types to be specified, check the operation
manual that came with the connected equipment.
Colour system setting (AV mode only)
If an image does not appear clearly, select another colour
system (e.g., PAL, NTSC).
1 Press HOME MENU.
2 Select “Option” ( / then ENTER).
3 Select “Colour System” ( / then ENTER).
4 Select a video signal system ( / then ENTER).
• You can select “Auto”, “PAL”, “SECAM”, “NTSC”, or
“4.43NTSC”.
• With “Auto” selected, input signals are automatically
identified.
5 Press HOME MENU to exit the menu.
NOTE
• The factory default is “Auto”.
• You need to perform colour system setting for each of INPUT
1, 2, 3, and 5.
• For the colour system setting, see steps 11 and 12 under
“Using Manual Adjust” (page 29).
Input Select
Video
S-Video
RGB
COMPONENT
Colour System
Auto
PAL
SECAM
NTSC
4.43NTSC
To Next Page
