THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 3
Jun 1/03
3E9
31-50-00
CHART 1 (Sheet 2 of 3)
TROUBLESHOOTING ANNUNCIATOR
Trouble Cause Remedy
ALTERNATOR INOP warning Blown fuse. Replace 1/4 amp fuse near
light fails to extinguish. the alternator.
No current from the fuse to Check all wire segments
the Alternator out switch. and connections.
Test switch fails to activate Bad switch or connections. Check wires and replace
warning lights. switch if necessary
ALTERNATOR INOP warning Diode heat sink shorted Replace teflon insulating
light fails to extinguish, ammeter to airframe. washers. Do not tighten
reads full output. screws excessively.
BAGGAGE DOOR light Bulb burned out. Replace bulb.
fails to operate.
No ground to switch. Check all wire segments
and connections.
Defective switch. Replace switch.
BAGGAGE DOOR light Switch terminals bridged. Remove material between
fails to extinguish. terminals.
Defective switch. Replace switch.
LOW BUS VOLTAGE light Bulb burned out. Replace bulb.
fails to operate.
No ground to monitor. Check wiring to monitor.
Sensor activates at too low
a setting. Replace sensor.
Defective sensor. Replace sensor.
LOW BUS VOLTAGE light 1A fuse open. Replace fuse.
fails to extinguish.
Sensor activates at too high
a setting. Replace sensor.
Defective sensor. Replace sensor.
AIR/COND DOOR OPEN light Bulb burned out. Replace bulb.
fails to operate.
No current to sensor. Check all wire segments
and connections.
Sensor activates at too low
a setting. Replace sensor.
Defective sensor. Replace sensor.
